dry pack traffic road marking line thermoplastic paint mix plant
What is traffic road line marking thermoplastic paint?
Thermoplastic road marking paint, also called hot melt marking paint, is a kind of powder paint. When applied as road surface markings, a hot melt kettle is used to heat it to 200 °C (392 °F) to melt the powder, after which it is sprayed on the road surface. The coating then becomes a hard, polymer line after cooling. This paint is a thick coating as is wear-resisting, bright and reflective. In recent years, practical applications tests have proved that the marking lines lack surface roughness and can easily cause wheel slip, resulting in a traffic accident in snow and rainy weather. Therefore, some countries once restricted the use of this paint. In order to increase the antiskid performance of the line, thermoplastic paint has added reflective glass beads. Thermoplastic can be used very effectively for large Anti-skid areas on roads and pedestrian walkways by adding glass beads. It can be produced in any colour and is great for car parks, factory walkways and many other areas. It's fast drying and can be driven over after just a few minutes.
Thermoplastic road constructions traffic road line marking paint is mainly includes dolomite powder, silica sand, glass bead,resin,titianium powder,PE wax, EVA, clay and pigment to finish different standard features of thermoplastic paint. Therefore, we must choose suitable equipment for each stage process as per these raw materails features. So, what is and how to choose road marking paint production plant?
What is road marking paint production plant?
Traffic road marking paint production plant is mainly used for the pre-production of marking paint. Its main role is to stir evenly and pack the pre-made marking paint into a bag of specific weight. There are different solutions and different cost traffic road marking paint production plant can be chose as per different production capacity, automatic level, raw materials coming methods, etc. The most simple thermoplastic paint production plant can be only a mixer, a screw conveyor and a special designed packer for thermoplastic paint. The small simple thermoplastic road paint mix plant is suitable for personal investment with low cost, this kind small simple thermoplastic road paint mixer is specially designed by Henan Ant Construction for the small producer of thermoplastic paint or a small road marking construction party. If you need a big output capacity thermoplastic road marking paint production plant, you can contact Ant Construction freely to get the most suitable solution as your actual demand.
How to make thermoplastic paint with above described thermoplastic road marking paint production plant?
No mater what output capacity or what automatic level thermoplastic road marking paint will you use, the operation process is similar, the whole process is as follows:
1, Prepare raw materials as formula.
Except the large-scale fully automatic Thermoplastic marking paint production line which automatically measures and distributes the proportions, the small prodution uses manual batching of raw materials proportion and puts the proportioned raw materials into the mixer manually for mixed production. The Thermoplastic marking paint mixer can mix powder materials and liquid materials.
2, Materials feeding.
The equipment equipped with a screw feeder directly which lifting the materials from ground to mixer. There are two feeding methods, one is to use a bucket elevator for vertical feeding, and the average feeding speed is 7 kg/s (tested with 200 mesh materials); the other is to use screw conveyor feeding inclinedly,this feeding equipment is low cost, easy production and equipment maintenance.
3, Mixing.
The mixing work is finished by thermoplastic paint mixer. Thermoplastic paint mixer is normally use single shaft ribbon bype mixer, mixing cycle time is about 20-30 minutes.
4, Packaging.
If the mixer equipped with a finished product silo, the air-flow valve port automatic packaging machine is connected to the finished product silo. After the material all discharged from the finished product silo, materials will be released to the packaging machine and the work only need one button operation to finish packing. If the equipment doesn't have a finished product silo, the valve port packaging machine is directly linked with the mixer discharge port for packaging. This packaging method is fast, time-saving and labor-saving.
Contact us now to find the best thermoplastic road marking paint production plant, for decades Ant Construction been focusing on the manufacturing of marking paint production line, the improvement of production formula, the selection of marking paint raw materials, choose us and beyond your expectations.
