Full Automatic Dry mortar Plant

Custom Make Quality Premix Dry Mortar Mixing Production Plant

Describe:
Modular design dry mortar wall putty processing and mixing plants-Your mixer specialist for dry mortar, limestone and all concrete building materials

We are here to help:Easy ways to get the answers you need.
Product Detail

Manufacturer Custom Make Quality Premix Dry Mortar Production Plant


1. What is dry mortar?

Dry mortar is polymer dry mixed mortar or premixed dry mortar. It is a kind of construction building material that cement and gypsum as the main base material. According to different building function requirements, mixed uniformly as a certain proportion of dry powder building aggregate materials and additives, etc. It can be  transported to the construction site in bags or bulk stadus and can be used directly after adding water. Common dry mortar products include dry powder tile adhesive, dry powder wall coating, dry powder wall mortar, dry powder concrete, etc. Actually dry mortar is a general name of a class serie products which includes a lot of different dry mixing cement, sand, gypsum such as these powder based products.


What is premix dry mortar production plant

Premix dry mortar production plant is a complete full dry mortar production line and system which includes raw materials storage, conveying, weighing and packaging process etc. According to different output capacity, automatic level and different type dry mortar products production, the premix dry mortar plant can be classified as below methods:

Classifications of dry mortar mix production plant

  • According to the output capacity and automatic level, the premix dry mortar production plant can be classified 1-5t/h simple dry mortar mix plant, semi automatic 5-15t/h dry mortar mix plant, automatic 15-30t/h dry mortar mix plant and complete full automatic 30-100t/h dry mortar mix plant

1-5t/h simple dry mortar mix plant

mmexport1558339015567.jpgMulti ribbons.jpg

Simple dry mortar plant is suitable for the small investment at initiation, it normally used a low speed multi ribbon mixer which is designed base on many years improvement, it is specially suitable for kinds of dry powder wall putty, tile adhesive, gypsum mixing.

  • Main features of simple premix dry mortar plant:

  1. Low investment for individuals,

  2. Simple operation, 2-3 workers are enough,

  3. Low maintenance,

  4. Cover small area,

  5. height is less than 3.5 meter, can be indoor production in small plant.

  6. 1 ton-2 ton per batch, 1-5 ton/h.

  • Working operation instructions of simple premix dry mortar plant:

  1. Start the screw conveyor, mixer and then feed the main raw materials to feeding port

  2. After finished the main raw materials as required proportion, add additives to mixer via the additives feeding port on top of mixer, mixing for 8-10 minutes, then start the second screw hoister to transport the mixed materials to end product silo and start to packing the materials.

  3. Start to feeding the materials for next batch once the mateirals in the mixer completely transported to end product silo

  4. The next one batch feeding work and previous one batch packing work can be going on at the same time, it is a continous production line, therefore, afater finish the first batch production, no need to wait first batch packing work and you can start next batch feeding work.

5-15 t/h Semi automatic premix dry mortar mix plant

semi automatic wall putty mix plant (1).jpgtwin shafts mixer inside (2).jpg

Semi automatic premix dry mortar mix plant has higher output capacity and working effeciency, even the semi auomatic dry mortar mix plant used twin shatfs non-gravity mixer and bucket elevator, it has the similar working princinple and almost the same working process as simple dry mortar mix plant.

Main features of semi automatic dry mortar mix plant

  1. Covers 30m2 area ,

  2. Small investment and quick refund,

  3. Easy operation (require 4 people to operate), etc.

  4. Height less than 8 meters, ordinary workshop can be use as factory production, this solve the problems of traditional dry mortar production line has to increase height of factory.

  5. It achieve function of manual batching raw materials, automatic mixing, automatic filling and packing at 15-50kg/bag

Working process procedure of semi automatic dry mortar mix plant please refer to simple dry mortar mix plant

Automatic 15-30t/h dry mortar mix plant

Self leveling mortar mix plant (1).jpgSelf leveling mortar mix plant (4).jpg

The main differences between automaitc dry mortar mix plant and semi automatic dry mortar mix plant are main raw materials silo and automatic weighing system for main raw materials. It is higher output capacity and working effeciency than semi automaitc dry mortar mix plant because main raw materials are automatically feeding and weighing, all the work of main materials feeding, transporting, weighing, mixing and packing are controlled on control cabinet, the control cabinet can store at least 6 different formula settings.

Self leveling mortar mix plant (6).jpg

Completely full Automatic 30-100t/h dry mortar mix plant

annually 200000t dry mortar plant ZJ customer (1).jpg

Completely full Automatic 30-100t/h dry mortar mix plant is higher automatic level and higher output capacity than automatic dry mortar mix plant, it is not only automatic weghing main raw materials, but also automatic weighing additives, meanwhile, the packing system can also use bulk tanker packing, the finished mixed dry mortar product can be storaged in a end product silo which equiped with bulk packer, the bulk pakcer can discharge the final dry mortar products to bulk tanker, meanwhile, the bag packed dry mortar can also use automatic stacking line.

annually 200000t dry mortar plant ZJ customer (7).jpgannually 200000t dry mortar plant ZJ customer (4).jpg

annually 200000t dry mortar plant ZJ customer (3).jpgannually 100000T dry mortar mix plant (5).jpg

Therefore, in order to help you to prepare the suitable dry mortar mix plant for you, please contact us and communicate your actual demand, output capacity requirement, main raw materials incoming stadus, what dry mortar products will you produce such as these information, then ask us to prepare a suitable professional solution for your production.


Modular design dry mortar wall putty processing and mixing plants

If the production of consistent, high quality yet economical and low emission dry mortars is your goal, Ant Construction machinery is your best choice in China.

With over 20 years of industry experience Ant Construction has been at the forefront of producing the dry mortar mix plant, at Ant Construction, we offer high quality products alongside expert advice and good customer service.
