Several common couplings in lime wall putty spiral mixer machine
Author：ANT CONSTRUCTIONS Comefrom： Createdate：2020/10/15 11:14:37 Hits：23
Several common couplings in lime wall putty spiral mixer machine
The elastic pin coupling of the putty powder mixer
The elastic pin coupling of the putty powder mixer uses a non-metallic material (usually nylon) pin to be placed in the flange holes of the two halves of the coupling to transmit torque. The flange end is provided with a retaining ring to prevent the pin slide out. The structure is simple, and the pin replacement is convenient, but the elastic deformation is smaller than that of the elastic sleeve. The elastic pin gear coupling of the putty powder mixer is divided into two rows and placed in a cylindrical tooth groove formed by the combination of two half couplings and a jacket. When working, the shear surface of the pin is an axial section, and the force is better, so the bearing capacity is stronger.
The mechanical coupling of the putty powder mixer
The mechanical coupling of the putty powder mixer selects the coupling dimensions, that is, the maximum radial and axial dimensions, and must be within the installation space allowed by the machine and equipment. Compared with the elastic sleeve pin coupling of the same size, the torque transmission capacity is larger, but the offset compensation capacity is smaller. It is suitable for the transmission with light load, frequent start or frequent change of forward and reverse rotation. Choose a coupling that is convenient for assembly and disassembly and doesnt't need maintenance, has a long maintenance period or is convenient for maintenance, does not need to move the two shafts to replace the wearing parts, and is easy to adjust the center. The two shafts connected by the coupling are easily caused by many factors such as manufacturing error, assembly error, installation error, deformation caused by shaft load, base deformation, bearing wear, temperature change, relative movement between components, etc. Relative displacement. Under normal circumstances, the relative displacement of the two shafts is unavoidable, but the dynamic balance displacement direction (ie, axial, radial, angular) and the magnitude of the displacement produced by the shaft transmission under different working conditions are different. Only the flexible coupling can compensate the relative displacement of the two shafts. Therefore, a large number of flexible couplings are selected for putty powder mixers in practical applications.
Universal couplings of the wall putty powder mixer
Rigid couplings are not compensatory, and their application range is limited, so the amount of putty powder mixer is very small. Universal couplings should be used for shafting transmissions with large angular displacement; for shafting transmissions with axial movement and need to control axial displacement, diaphragm couplings should be used; only those with high centering accuracy requirements Rigid couplings are selected only under circumstances. Flexible couplings with metal elastic elements generally have a longer service life than flexible couplings with non-metal elastic elements.
The couplings advtanges used by Ant Construction Machinery
The couplings used in Ant Construction putty powder mixer putty powder production line equipment, real stone paint mixer, inorganic thermal insulation mortar equipment, etc. have undergone strict calculation and testing, and have undergone strict inspection before leaving the factory, so as to provide customers with cost-effective products, our professional team of engineers will serve you wholeheartedly!
