Automatic bag palletizer machine for tile adhesive
Gengeral introdutions-Automatic bag palletizer machine for tile adhesive
Automatic Bag Palletizer Machine is a kind of mechanical equipment which can finish the palletizing of various commodities according to the palletizing request set in advance.Automatic Palletizer Machine use preemptive skills and controls. The optimized planning of professional skills team makes the palletizing compact, regular and beautiful. The rapid palletizing speed and stable function have become the choice of palletizing work for many companies.Usually the machine can automatically finish a series of work, such as flattening, slow stop, transposition, bag pushing, palletizing and so on.
Automatic high level bag palletizer can stack bigger pallet with higher level and speed compared to the robot palletizer and low level palletizer; high-levelr palletizer is a dedicated high-speed automatic palletizing Equipment. High-level palletizing machine will be transport bags to a certain height, according to PLC program, then bags will be translocated, grouped, pushed and stacked on the pallet, finally the full pallet will be conveyed out the system.
Parameters-Automatic bag palletizer machine for tile adhesive
Item | FULL AUTOMATIC PALLETIZING MACHINE |
Stacking type | 5/6/7/8/9/10 bags per layer or customized, stacking height≤1.5m
1, 9layer/50packages:6bags/layer*8layer+2bags*1layer=50bags
2, 9layer/54packages:6bags/layer*9layer=54bags
3, 10layer/50packages:5bags/layer*10layer=50bags |
Pallet size | 1.6*1.4m, 1.5*1.3m or customized as you need |
Stacking Capacity | 450-500bags/hour(40kg/bag) |
System | PLC system and 10" full touch screen panel (HMI) |
Air source | 0.6-0.8Mpa,0.8Nm³/h |
Dimension(L*W*Hmm) | 4500*2300*3100mm(mainframe,not including the conveyor. Final as per the confirmed produce drawing. |
Power | 11.02kw |
Voltage | single/three phase AC220V/AC380V/50HZ |
Working environment | （-10℃~40℃） |
Relative humidity | ≤90%RH non condensation |
Machine materials | Q235 carbon steel with anti-rust painting |
Advantages feature-Automatic bag palletizer machine for tile adhesive
Automatic Bag Palletizer Machine can stack bigger pallet with higher level and speed compared to the robot palletizer and low level palletizer. Automatic bag palletizier machine has the advantages of optimized construction planning and stable and reliable movement. The palletizing process is completely automatic, and there is no need for manual intervention in normal work, so it has a universal scope of application.
Grab waiting conveyor
Mechanical inverting conveyor & square tube vibration conveyor
Leveling conveyor
Working principle-Automatic bag palletizer machine for tile adhesive
Weighing and sealing bag →Conveying→flattened Bag→Conveying→Automatic stacking bag on the pallet→Taking out pallet with forklift
