wholesale price dry mortar plant automatic palletizer machine
Main parameters- dry mortar plant automatic palletizer machine
Model | HL-400 | HL-600 |
Palletizing Speed | 500 Bag/Hour | 650 Bag/Hour |
Host Size | 3200*2200*3000mm | 3500*2400*3200mm |
Device Power | 7.5kw | 11kw |
Supply Power | 3*AC38+N | 3*AC38+N |
Palletizing Height | 600-1600mm | 600-1600mm |
Palletizing Layer | 1-10 Layer | 1-12 Layer |
Pelletizing Station (Number of palletizing bags per layer ) | 3-12 | 3-12 |
Gas Supply Pressure | 0.6-0.8Mpa | 0.6-0.8Mpa |
Weight | 3000kg | 3400kg |
Gengeral introdutions-dry mortar plant automatic palletizer machine
Automatic Bag Palletizer Machine is a kind of mechanical equipment which can finish the palletizing of various commodities according to the palletizing request set in advance.Automatic Palletizer Machine use preemptive skills and controls. The optimized planning of professional skills team makes the palletizing compact, regular and beautiful. The rapid palletizing speed and stable function have become the choice of palletizing work for many companies.Usually the machine can automatically finish a series of work, such as flattening, slow stop, transposition, bag pushing, palletizing and so on.
Fully automatic bag palletizier is suitable for palletizing of big bags, such as fertilizer, flour, cement, rice, chemical raw materials and feed stuffs.The use of touch-screen operation is to achieve man-machine dialogue, which show the production speed, the cause of the malfunction and location, a high degree of automation.It uses PLC programmable bag sorting layer stacking, and pallet supply and discharge can be programmed into the program control.High quality chain with good wear resistance ensures high precision, stable transmission and so on.Imported pneumatic components and cylinders ensures high quality and reliable performance.
Advantage features and details-dry mortar plant automatic palletizer machine
Automatic Bag Palletizer Machine can stack bigger pallet with higher level and speed compared to the robot palletizer and low level palletizer. Automatic bag palletizier machine has the advantages of optimized construction planning and stable and reliable movement. The palletizing process is completely automatic, and there is no need for manual intervention in normal work, so it has a universal scope of application.
