Waterproof floor tile adhesive grout 1 ton mixer machine
Introductions-Waterproof floor tile adhesive grout 1 ton mixer machine
Tile adhesive grout manually batching 1 ton mixer machine can realize Automatic Conveying Material, Automatic Mixing, Automatic Filling and Automatic Packing, high efficiency and low cost, wihch is the priority selection of small and medium dry mix tile adhesive factory.
Simple tile adhesive grout mix plant can equip with 1 ton ribbon mixer or more than one ton ribbon mixer with single or double packing machines to reach the output capacity from 2-10t/h. This kind ribbon mixer is specially suitable for producing Putty powder, Tile adhesives,tile glue, Thin set coating, Masonry mortar, Plaster mortar, Screed mortar,Bonding mortar,AAC jointing mortar, dry sand mixture, Insulation mortar,Decoration mortar and etc.
1. Horizontal ribbon mixer plant height is less than 3.2 meters, twin shaft paddle mixer plant height is less than 4.2 meters, both occupation area 15~ 20 square metres , ordinary houses can be use as factory production, this solve the problems of traditional dry mortar production line has to increase height of factory.
2. It achieve function of manual batching raw materials, automatic mixing, automatic filling and packing at 15-50kg/bag , under a small investment, and less labor.
3. It is one of the most simple and practical dry mortar production line.
Main parameters-Waterproof floor tile adhesive grout 1 ton mixer machine
Output capacity | 2-5t/h |
Mixer | multi ribbons drum mixer |
Mixing cycle | 10-15 minutes |
Power | 22 kw |
Power supply | small generator or industry electric source, 380/220V |
Plant area | 20m2 |
Workers | 1-2 persons |
Application | industrial building materials mixing |
Application-Waterproof floor tile adhesive grout 1 ton mixer machine
1.Masonry mortar
2.Thin and smooth wall mortar.
3.Hand-plastering screeding mortar.
4.Colored coating mortar.
5.Water-proof mortar.
6.Plaster powder.
7.Wall plastering mortar.
8.Ceramic tile adhesive mortar.
9.Self-leveling mortar.
10.Heat-preservation mortar.
11.Repairing mortar.
12.Gap filler.
Features-Waterproof floor tile adhesive grout 1 ton mixer machine
Small dry mortar plant is used for producing dry mortar which productivity is 1-5t/h. It includes Screw mixer,Screw elevator,Vertical finished production silo,Valve packing machine, also include air compressor,cable ,electric wires, electric control cabinet etc.
1. Low investment for individuals,
2. Simple operation,
3. 2-3people can operate,
4. Low maintenance,
5. Cover small area,
6. height is less than 3meter,ordinary houses can plant,
7. 1 ton-2 ton per batch, 1-5 ton/h.
How to choose suitable dry mortar tile adhesive mix machine:
There can be divided into 3-4 types classic main configurations solution as per the output capacity, main raw materials and additives feeding automatic level, packing process automatic level. Of courese, it doens't means the more expensive or higher automatic level the better, you should choose the suitable dry mortar mix plant as per your actual demand and actual raw materials situation and what product will you produce.
1. Firstly, you should have an idea how many ton end product do you need to produce, output capacity is very important and this largely determines the scale and cost of the production line
2. Is sand dry sand available in your local, if not, one sand dryer is necessary for you because the dry mixing mortar requires sand moisture less than 0.5%, then consider what fuel for sand dryer is cheap and easy to get in your local.
3. What packing mode will you choose, choose a suitable packing mode as you want from 20-50kg bag, ton bag, tulk tanker, etc.
4. What product will you produce exactly, tell as more details as possible to your supplier consultants.
5. If possible,provide your working shop layout to your supplier for designing the solution as your actual situaiton.
6. All other details need to be attention, tell your consulator in advance.
