Limestone pebble stone making sand production line
Main applications-Limestone pebble stone making sand production line
VSI sand making machine is widely used for fine crusher and coarse grinding of metal and non metal ores, cement, refractory material, grinding material, glass raw material, building aggregates, artificial sand and all kinds of metallurgical slags. It is especially suitable for medium hardness materials, high hardness materials and corrosion resistance materials, such as carborundum, emery, magnesia etc.
General introductions-Limestone pebble stone making sand production line
Limestone pebble stone processing sand production line is also called a vertical sand making machine.It can process all kinds of rock,gravel and river pebbles to be used in construction and with various grain sizes.The sand has uniformity of plasmid and high compressive strength.It is far more in line with the construction requirements than the sand produced by natural sand and ordinary hammer sanding machine and can improve the building quality.
Limestone pebble stone processing sand production line is the necessary equipment for the mechanism sand.It adopts the principle and technology of the"stone hitting stone" crusher,which makes the finished product with excellent grain shape,reasonable gradation and improved production efficiency,especially suitable for artificial sand making and stone shaping.
It can supply high quality sand aggregate for high building,expressway(railway) construction,municipal engineering,large scale irrigation establishment,concrete batching plant and many other areas.
Parameters-Limestone pebble stone making sand production line
| Model | Sanding making | Reshaping | Sanding making | Reshaping | Speed (r/min) | Power (kw) | Overall dimension (mm) |
| Maximum feeding size (mm) | Throughput (t/h) |
| VSI6T1263 | 50 | 60 | 454-486 | 545-583 | 900-1200 | 315×2 | 5700×2980×4190 |
| VSI6T1150 | 45 | 55 | 344-368 | 413-442 | 1000-1300 | 250×2 | 5500×2750×3950 |
| VSI6T1040 | 40 | 50 | 264-283 | 317-342 | 1100-1400 | 200×2 | 4880×2560×3725 |
| VSI6T9026 | 35 | 45 | 167-179 | 200-215 | 1200-1500 | 132×2 | 4200×2400×3150 |
| VSI6T8018 | 30 | 40 | 109-117 | 131-140 | 1300-1700 | 90×2 | 4100×2300×2750 |
Advantages-Limestone pebble stone making sand production line
1.Large handing capacity and high output.
2.Low wearing parts cost.
3.Perfect product shape.
4.Hydraulic devices are maintained easily.
5.Thinning oil lubricant and automatic.
6.Multi-functions and Flexible application.
In consideration that the customer has two production demands (i.e. sand making and shaping) and will switch the modes of sand maker between central feeding and fall feeding, we make a brand new improved design to the material distributing tray. When switching the production demand, the operator only needs to gently move the flapper of the material distributing tray to complete the mode switch, which greatly reduces the adjustment downtime and manual operation cost.
